Description
SONIC 2.5″ Selectable Color Trims
The Rayhil Sonic Downlights boast an exceptional 90+ CRI light while simultaneously reaching substantial lumen counts on each model. The sleek design of the Downlights are just as practical as they are appealing. Air-tight and wet location approved, as well as Type IC rated – approved for direct contact with insulation. They are also equipped with an Isolated driver inside a junction box. Available in multiple color temperatures, trim colors and shapes, as well as sizes.
For the 9W Click Here
For the 14W Click Here
- Air-tight and wet location approved
- Type ic rated – approved for direct contact with insulation
- Downlight housing is not required even for insulated ceilings
- Spring loaded mounting clips
- Quick connect wire allows for efficient installation
- Isolated driver inside junction box
- New construction plate available (NCH250*)
- Optional Emergency Backup
- 5 year warranty
*Click Here for Construction Plates
Square Dimensions
|
||||||
Round Dimensions
|
Spec Sheet
Spec Sheet
Installation Instructions
Info
| Wattage | 9/14W |
| Lumen | 800/1100lm |
| Efficacy(LPW) | >82 lm/W |
| Color Temp | 27K, 30K, 35K, 40K, 50K |
| CRI | >90 |
| Dimming | Triac/ 0-10V |
| Lamp Life | 50,000hr |
| Environment | IP65 Wet Location |
| Cutout | 2.36″ |
