Description

Belimo AFB24-MFT Damper Actuator, 180 in-lb [20 Nm], Spring return, AC/DC 24 V, 2..10V, MFT/Programmable

Technical Specifications:

Actuator Type: Spring return

Angle of Rotation: 95

Control Type: MFT/Programmable

Degree of Protection: IP54, NEMA 2, Enclosure Type 2

Direction of Rotation (Fail-Safe): Reversible with cw/ccw mounting

Electrical Connection: Cable

Power Consumption (Holding): 3 W

Power Consumption (Running): 7.5 W

Running Time (Fail-safe): <20 s

Running Time (Motor): 150 s / 90°

Running Time Range (Motor): 70… 220s

Safety Function: YES

Shaft Diameter: 1/2…1.05″ Round, Centers On 1/2″ And 3/4″ With Insert, 1.05″ Without Insert

Torque: 180 in-lb [20 Nm]

Voltage AC/DC: AC/DC 24 V

Product & Technical Literature:

• Belimo Technical Data Sheet
• Belimo Installation Instructions
