Acudor RHG3844 30″ x 36″ Galvanized Ladder Access Roof Hatch
Project Pricing, Discounts, & Custom Sizes Available. Please contact us at info
Application:
- Acudor ladder access roof hatches are designed to provide convenient economical access to the roof of the building.
Features & Benefits:
- Weather tight construction.
- 12″ high insulated curb.
- G90 galvanized steel.
- Stainless steel hardware.
- Convenient one hand operation.
- Supports 40lbs/sqft live load.
Door Specifications:
- Cover: Double skin construction with 1″ polyiso R6 insulation and continuous EPDM foam weather / draft seal gasket that is attached to the inside of the cover to provide a flush, tight fit. Designed to support a live load of 40lbs/sqft, the cover is 14 gauge galvanized steel with a 22 gauge galvanized steel inside liner.
- Curb: 14 gauge galvanized steel with 1″ thick polyiso R6 insulation at curb exterior. Curb is 12″ high with 3.375″ wide bottom flange an pre-drilled mounting holes.
- Hinge: Heavy duty aluminum pintle hinges with 3/8″ SS pin.
- Opening: Gas Spring operators allow cover to open and close with ease. Stainless Steel inside pull handle allows for easy control when closing cover.
- Door Latch: Self latching, stainless steel outside T handle with stainless steel inside lock and lever assembly. Heavy Duty detention lock with paracentric key. Unit also has inside and outside padlock provisions.
- Finish: Mill.
Options:
TSP-1: Telescope Safety Post offers safe accessibility to roof areas through hatch.SLE-Y: Safety Ladder Extension offers safe accessibility to roof areas through hatch.
RH-RGS: Safety Rail System with Self Closing Gate Designed to Meet OSHA Standards.
Technical Documentation:
Acudor RHG Galvanized Ladder Access Roof Hatch Product Page: Click Here.
Acudor RHG Galvanized Ladder Access Roof Hatch Specification Submittal: Click Here.
Acudor RH-RGS Safety Rail System Product Page: Click Here.
Acudor RH-RGS Safety Rail System Specification Submittal: Click Here.
