Description
Taco 0026e cast iron model is a variable speed circulator pump w/ a high-efficiency ECM permanent magnet, ideally suited for large residential and light commercial hydronic and radiant heating projects.
Cross-References:
- Taco: 2400-10, 2400-20, 2400-30, 2400-40, 110, 111, 112, 113, 0010, 0011, 0012, 0014 Series
- Grundfos: UP50-75, UPS50-44, UP43-75, UPS26-99, UP26-96, UP26-64, UPS32-80, Alpha2 26-99, Magna 32-60
- B&G: PL-30, PL-50; Series 60, Series e; Series HV, PR, 100; NRF36; ecocirc XL 20-35, 36-45
- Armstrong: E7, E10, E11, E13; H32, H51, H52, S25; Astro 210, 280; Compass ECM
- Wilo: Stratos 1.25×3-25, 1.25×3-20; Top S: 1.25×15, 1.25×20, 1.25×25; Top Z: 1.5×15, 1.5×20
Features:
- Highly capable circulator with (5) mode settings, including variable speed (w/ constant or proportional pressure) and fixed speed
- Replaces a large number of Taco 0010, 0011, 0012 and 0014 models
- High-efficiency ECM motor uses up to 85% less electricity
- SureStart automatically frees locked rotor condition and self purges air from pump
- Double insulated (no ground wire required)
- Whisper-quiet operation
Technical Specifications:
- Casing: Cast Iron
- Type: ECM circulator pump with 5 modes – TacoAdapt, (3) Fixed Settings – Low (Constant Pressure), Medium (Const. Pr.) & High (Fixed Speed), and 0-10VDC (or PWM) external input.
- Connections: Flanged
- Performance (TacoAdapt mode): see chart or specs sheet for curves
- Hi, fixed speed mode: 0-44 GPM, 0-26ft of head
- Medium mode, constant pressure: 16ft of head
- Low mode, constant pressure: 8ft of head
- 0-10V DC mode: see chart or specs sheet for curves
- Operating Temperature Range: 14°F – 230°F
- Max Operating Pressure: 150 psi
- Electrical Specs: 115/208/230V, 50/60 Hz, Single Phase, 120W max, 1.0 Amps max @ 115V or 0.50 Amps max @ 230V
- Hydraulic Institute Energy Rating: ER 154, CEI 0.45
- Fluids: Water or 50% Water/Glycol Solution
Warranty:
3-year warranty
