Description
Cast Iron Taco 0010-F3-1IFC Circulator Pump with an Integral Flow Check (IFC) is designed to reduce installation costs when using Taco 0010 circulators. The bulit-in IFC increases the flow performance when compared to regular in-line check valve. Taco 0010-F3-1IFC model can be used for medium head, medium/higher flow residential or light commercial applications such as hydronic heating, radiant floor heating, and hydro-air fan coils. Both the IFC (Integral Flow Check) and circulator pump cartridge are easily accessed for service and eliminate the need for replacing the entire unit.
Applications:
- Hydronic Heating/Cooling
- Radiant Heating
- Zoning with Pumps
- Hydro-Air Fan Coils
- And others
Cross-References:
- Grundfos UPS15-58FC @ spd 3.
Technical Specifications:
- Connection Sizes: 3/4″, 1″, 1-1/4″, 1-1/2″ Flanged
- Voltage: 115V;
- Hertz: 60Hz;
- Phase: 1;
- Amps: 1.10A;
- HP: 1/8HP;
- Flow Range: 0 – 30 GPM
- Head Range: 0 – 9 Feet
- Minimum Fluid Temperature: 40˚F (4˚C)
- Maximum Fluid Temperature: 230°F (110˚C)
- Maximum Working Pressure: 125 psi
Warranty:
3-year manufacturer’s warranty.
